2 bore x 30 stroke hydraulic cylinder, welded cross tube double acting cylinder | Magister Hydraulics
On sale!
Zoom

2" bore x 30" stroke cross tube hydraulic cylinder

$255.00

Pay in 4 interest-free payments of $63.75
* Wholesale Discount is available for this product if you purchase 4 or more products.
SKU: WCT 2x30
Bore : 2 in
Outer Dia. (⌀) : 2.38 in
Stroke : 30 in
Rod Dia. (⌀) : 1.25 in
Port Size : SAE 6
Pin Dia. (⌀) : 1 in
Extended : 68 in
Retracted : 38 in
Overall length : 39.5 in
Pressure : 3500 PSI
Column Load : 5,700 LBs
Oil Volume : 1.63 QTs
Brand : Magister Hydraulics
Design : Welded
Rod Type : Chrome Plated
Rod End : Cross Tube
Action :
  • Double Acting
  • Weight : 30 LBs
    GTIN : 850597006806

    Volume discounts

    1+ PRICE EA
    $255.00
    4+ PRICE EA -5%
    $242.25
    8+ PRICE EA -10%
    $229.50
    In stock

    74 in stock

    Description

    • 2″ bore x 30″ stroke cross tube hydraulic cylinder 3500 PSI. Heavy-duty hydraulics, 2-year warranty, free ground Continental US shipping. Magister cylinders manufactured using steel piston and steel threaded gland with wear rings for long life. Welded cross tube ends, honed cold-drawn tubing, hard chrome plated rod and top quality five component piston seals allow Magister Hydraulics cylinders to work in extreme conditions. Excellent replacement for front end loader.
    • Applications: Welded Double Acting Hydraulic Cylinder.
    • Color: Black.

    NOTE! Chrome-plated rod is NOT induction hardened (Temperature treated). Possible bent rod is a result of a misuse(wrong measurements or type of application), such cases not covered under warranty!

    Same-Day Shipping: all orders, made until 3 pm, will be shipped the same day (except weekends and holidays).

    Free Ground Continental US Shipping

    Tariff-FREE cylinders.

    Made in Europe.

    If you need assistance to choose a proper hydraulic cylinder replacement, do not hesitate to contact us:
