1 spool x 32 GPM hydraulic control valve

$279.00

Pay in 4 interest-free payments of $69.75
* Wholesale Discount is available for this product if you purchase 4 or more products.
SKU: HCV 1x32
Flow :32 GPM
Pressure :3625 PSI
Inlet Port :SAE 16
Spool Type :4-way 3 pos Open Center
Outlet Port :SAE 16
Spool Action :3-pos Spring center
Working Ports :SAE 16
Brand :Badestnost
GTIN :850016509833
1+ PRICE EA
$279.00
4+ PRICE EA -5%
$265.05
8+ PRICE EA -10%
$251.10
In stock

38 in stock

DESCRIPTION

1 spool x 32 GPM hydraulic control valve with max pressure of 3625 PSI. Heavy-duty manual hydraulic valve, durable cast iron monoblock body, spools are made of carburized steel with hard chrome plating, free ground shipping & 1-year warranty. This control valve is designed to manage and direct hydraulic oil flow between hydraulic pumps, hydraulic cylinders, motors, tanks, etc. Made in Europe utilizing American standards, can operate under temperature anywhere from – 40F and up to 140F. Tariff free control valve. Excellent replacement for small tractors, tractor loaders, log splitters, forklifts and tow trucks.
Mounting with 3 bolts M10 size. Handles can be installed vertically or horizontally, included with the control valve.

  • FREE SHIPPING

We provide volume discounts for all our standard Hydraulic control valves. When purchasing 4-9 ea, 5% discount. When purchasing 10+ ea, 10% discount.

Tariff-FREE Hydraulic control valves.
Made in Europe.
If you need assistance to choose a proper hydraulic cylinder replacement, do not hesitate to contact us:
