1 spool x 13 GPM hydraulic control valve motor center


Pay in 4 interest-free payments of $26.25
* Wholesale Discount is available for this product if you purchase 4 or more products.
SKU: HCV 1x13-MC
Number of Spools :1
Flow :13 GPM
Pressure :3600 PSI
Inlet Port :SAE 10
Spool Type :Motor center 4-way 3 pos
Outlet Port :SAE 10
Spool Action :3-pos Spring center
Working Ports :SAE 8
Brand :Badestnost
GTIN :850033934540
4+ PRICE EA -5%
8+ PRICE EA -10%
In stock

36 in stock


1 spool x 13 GPM hydraulic control valve motor center with max pressure of 3600 PSI. Heavy-duty hydraulic valve, durable cast iron monoblock body, free ground shipping & 1-year warranty. This control valve is designed to manage and direct hydraulic oil flow between hydraulic pumps, hydraulic cylinders, motors, tanks, etc. Made in Europe utilizing American standards, can operate under temperature anywhere from – 40F and up to 140F. Tariff free control valve. Excellent replacement for small tractors, tractor loaders, log splitters, forlifts and tow trucks.
Mounting with 2 bolts M8 size. Handles can be installed vertically or horizontally, included with control valve.


We provide volume discounts for all our standard Hydraulic control valves. When purchasing 4-9 ea, 5% discount. When purchasing 10+ ea, 10% discount.

Tariff-FREE Hydraulic control valves.
Made in Europe.
If you need assistance to choose a proper hydraulic cylinder replacement, do not hesitate to contact us:
