3" bore x 48" stroke cross tube hydraulic cylinder

$355.00

* Wholesale Discount is available for this product if you purchase 4 or more products.
WCT 3x48
Bore :
3 inch
OD :
3.37"
Stroke :
48 inch
Rod :
1.5"
Port Size :
SAE 8
Pin :
1"
Extended :
104"
Retracted :
56"
Overall length :
57.5"
Pressure :
3500 PSI
Column Load (LBs) :
6,200
Oil Volume (quarts) :
5.87
Brand :
Magister Hydraulics
GTIN :
854335007995
1+ PRICE EA
$355.00
4+ PRICE EA -5%
$337.25
10+ PRICE EA -10%
$319.50
In stock

20 in stock

DESCRIPTION

  • 3″ bore x 48″ stroke cross tube hydraulic cylinder 3500 PSI. Heavy-duty hydraulics, 2-year warranty, free ground Continental US shipping. Magister cylinders manufactured using steel piston and steel threaded gland with wear rings for long life. Welded cross tube ends, honed cold-drawn tubing, hard chrome plated rod and top quality five component piston seals allow Magister Hydraulics cylinders to work in extreme conditions. Excellent replacement for front end loader.
  • Applications: Welded Double Acting Hydraulic Cylinder.
  • Color: Black.
  • FREE SHIPPING

We provide volume discounts for all our standard cylinders. When purchasing 4-9 ea, 5% discount. When purchasing 10+ ea, 10% discount.

Tariff-FREE cylinders.
Made in Europe.
If you need assistance to choose a proper hydraulic cylinder replacement, do not hesitate to contact us:
973-344-5313
