4 spool x 13 GPM solenoid hydraulic control valve

$649.00

Pay in 4 interest-free payments of $162.25
* Wholesale Discount is available for this product if you purchase 5 or more products.
SKU: HCV-S 4x13
Spools : 4
Flow : 13 GPM
Pressure : 3625 PSI
Inlet Port : SAE 10
Spool Type : 4-way 3 pos Open Cntr
Outlet Port : SAE 10
Spool Action : 3-pos Spring center
Working Ports : SAE 8
Brand : Badestnost
Operation : Electrical 12 V DC
Weight : 22 LBs
GTIN : 850016509888

Volume discounts

5+ PRICE EA -5%
$616.55
10+ PRICE EA -10%
$584.10
In stock

44 in stock

Description

4 spool x 13 GPM solenoid 12V DC hydraulic control valve with max pressure of 3625 PSI. Heavy-duty hydraulic control valve solenoid operated, durable cast iron monoblock body, free ground shipping & 1-year warranty. This control valve is designed to manage and direct hydraulic oil flow between hydraulic pumps, hydraulic cylinders, motors, tanks, etc. Made in Europe utilizing American standards, can operate under temperature anywhere from – 40F and up to 140F. Tariff free control valve. This is a perfect choice whether for a new design or replacement for small tractors, tractor loaders, log splitters, forklifts and tow trucks.

Mounting with 2 bolts M8 size.

Same-Day Shipping: all orders, made until 3 pm, will be shipped the same day (except weekends and holidays).

Free Ground Continental US Shipping

Tariff-FREE Hydraulic control valves.

Made in Europe.
