1.5 bore x 10 stroke Western 1 pin Snow Plow single acting hydraulic cylinder | Magister Hydraulics

1.5" bore x 10" stroke snow plow Western hydraulic cylinder 1" pin


Pay in 4 interest-free payments of $34.75
* Wholesale Discount is available for this product if you purchase 4 or more products.
SKU: WSP 1.5x10W10
Bore : 1.5 in
Outer Dia. (⌀) : 2.125 in
Stroke : 10 in
Rod Dia. (⌀) : 1.5 in
Port Size : 1/4" NPT
Pin Dia. (⌀) : 1 in
Extended : 27.5 in
Retracted : 17.5 in
Overall length : 18.75 in
Pressure : 2500 PSI
Push Force : 5,895 LBs
Oil Volume : 0.42 QTs
Brand : Magister Hydraulics
Design : Welded
Rod Type : Chrome Plated
Rod End : Pin Hole
Action : Single Acting
Weight : 15 LBs
GTIN : 854335007087
SKU: WSP 1.5x10W10 Categories: ,

Volume discounts

4+ PRICE EA -5%
8+ PRICE EA -10%
In stock

14 in stock


1.5″ bore x 10″ stroke snow plow hydraulic cylinder 2500 PSI. Replacement for Western snow plow with 1″ pin holes. Heavy-duty hydraulics, 2-year warranty, free ground Continental US shipping. Magister cylinders manufactured using rigid heavy duty design for excellent performance in severe winter. Honed tubing, hard chrome plated rod and top quality seals allow Magister Hydraulics snow plow cylinders to work in extreme conditions.

  • Applications: Welded Single Acting Hydraulic Cylinder
  • Color: Black.

NOTE! Chrome-plated rod is NOT induction hardened (Temperature treated). Possible bent rod is a result of a misuse(wrong measurements or type of application), such cases not covered under warranty!

Same-Day Shipping: all orders, made until 3 pm, will be shipped the same day (except weekends and holidays).

Free Ground Continental US Shipping

Tariff-FREE cylinders.

Made in Europe.
