1/2″ Flat Face Hydraulic Quick Couplers Set - 3/4″ NPT Port

SKU: HQC-FF-08B-12N-SET

$39.00

In Stock

Volume Discounts

2+ PRICE EA -5%
$37.05
4+ PRICE EA -10%
$35.10

228 in stock

View cart
US Customer Support
* Wholesale Discount is available for this product if you purchase 2 or more products.

Upgrade your hydraulic system with this 1/2″ Flat Face Hydraulic Quick Disconnect Set Fitting with 3/4″ NPT Thread. Designed for leak-free performance, these couplers deliver reliable connections in high-pressure applications without fluid loss or contamination.

Built from hardened steel with anti-corrosion plating, this set is engineered to withstand daily use in demanding environments. Max pressure up to 6,300 PSI and 23.8 GPM flow, it provides the strength and efficiency professionals depend on.

The flat-face design makes it easy to connect and disconnect under pressure while reducing spillage, ensuring a cleaner, safer hydraulic system. Perfect for use with skid steers, tractors, loaders, and other heavy equipment.

Key Features:

  • Leak-Free Performance: Flat face design significantly reduces fluid loss and air entry, maintaining system integrity and cleanliness.
  • High-Pressure Capability: Rated up to 5,075 PSI with a rated flow of 12 GPM for efficient hydraulic operations.
  • Durable Construction: Made from hardened carbon steel with zinc-nickel plating for superior corrosion resistance and long-lasting durability.
  • Easy Operation: Single-handed push-connect design allows for quick, effortless connections without special tools.
  • Enhanced Safety: Nipple seal resists blow-outs and locking sleeve prevents accidental disconnections.
  • Universal Compatibility: Fully interchangeable with other ISO 16028 standard couplings, ensuring seamless integration across various hydraulic systems

Highly competitive pricing. Covers Included

Compatible with many hydraulic tools and equipment

1 Year Warranty

QUICK COUPLERS SIZE CHART

Same-Day FedEx Shipping.

If you need assistance, do not hesitate to contact us:

973-344-5313

View Full Specifications

Specifications

1/2″ Flat Face Hydraulic Quick Couplers Set - 3/4″ NPT Port
SKU: HQC-FF-08B-12N-SET
Configuration SET ISO Body Size 1/2"
Design Flat Face Port Size 3/4" NPT
ISO Standard 16028 Locking Type Ball
Max Pressure 6300 PSI Working Pressure 5075 PSI
Max Flow 23.8 GPM Rated Flow 12 GPM
Dash Size 8 Weight 1.8 LBs
Plating Zinc-Nickel Brand Magister Hydraulics
GTIN 850081310129

Alternative part numbers

Manufacturer Male SKU Female SKU
Summit FF12M-12N FF12F-12N
Parker FEM-502-12FP FEM-501-12FP
Safeway FFE491-6 FFE495-6
Faster FFH08 34NPT M FFH08 34NPT F
Eaton FD89-1002-12-08 FD89-1001-12-08
SnapTite 74N8-12F 74C8-12F
Stucchi 800801009 800801008
Dixon HT4F6 4HTF6
DNP FF-HPG-08-12N-NPT FF-HPG-08-12C-NPT
Tomco EP4-31 EC4-31
The dimensions may be different. Please review the drawings prior to ordering. Magister Hydraulics does not guarantee the identical product match.
