1/4″ Flat Face Hydraulic Quick Couplers Set - 3/8″ SAE Port

SKU: HQC-FF-04B-06S-SET

$35.00

In Stock

Volume Discounts

2+ PRICE EA -5%
$33.25
4+ PRICE EA -10%
$31.50

457 in stock

View cart
US Customer Support
* Wholesale Discount is available for this product if you purchase 2 or more products.

Upgrade your hydraulic system with this 1/4″ Flat Face Hydraulic Quick Disconnect Set Fittings with 3/8″ SAE #6 ORB Port (9/16″-18 UNF Thread). Designed for leak-free performance, these couplers deliver reliable connections in high-pressure applications without fluid loss or contamination.

Built from hardened steel with anti-corrosion plating, this set is engineered to withstand daily use in demanding environments. Max pressure up to 7,350 PSI and 6.34 GPM flow, it provides the strength and efficiency professionals depend on.

The flat-face design makes it easy to connect and disconnect under pressure while reducing spillage, ensuring a cleaner, safer hydraulic system. Perfect for use with skid steers, tractors, loaders, and other heavy equipment.

Key Features:

  • Leak-Free Performance: Flat face design significantly reduces fluid loss and air entry, maintaining system integrity and cleanliness.
  • High-Pressure Capability: Rated up to 5,800 PSI with a rated flow of 3.2 GPM for efficient hydraulic operations.
  • Durable Construction: Made from hardened carbon steel with zinc-nickel plating for superior corrosion resistance and long-lasting durability.
  • Easy Operation: Single-handed push-connect design allows for quick, effortless connections without special tools.
  • Enhanced Safety: Nipple seal resists blow-outs and locking sleeve prevents accidental disconnections.
  • Universal Compatibility: Fully interchangeable with other ISO 16028 standard couplings, ensuring seamless integration across various hydraulic systems

Highly competitive pricing. Covers Included

Compatible with many hydraulic tools and equipment

1 Year Warranty

QUICK COUPLERS SIZE CHART

Same-Day FedEx Shipping.

If you need assistance, do not hesitate to contact us:

973-344-5313

View Full Specifications

Specifications

1/4″ Flat Face Hydraulic Quick Couplers Set - 3/8″ SAE Port
SKU: HQC-FF-04B-06S-SET
ConfigurationSETISO Body Size1/4"
DesignFlat FacePort Size3/8" SAE
ISO Standard16028Locking TypeBall
Max Pressure7350 PSIWorking Pressure5800 PSI
Max Flow6.34 GPMRated Flow3.2 GPM
Dash Size4Weight0.7 LBs
PlatingZinc-NickelBrandMagister Hydraulics
GTIN850081310051

Alternative part numbers

ManufacturerMale SKUFemale SKU
SummitFF14M-06SFF14F-06S
ParkerFEM-252-6FOFEM-251-6FO-NL
FasterFFH04-28/12S MFFH04 28/12S F
EatonFD89-1004-06-04FD89-1005-06-04
SnapTite74N4-6EF74C4-6EF
Stucchi800804001801304004
DixonHT2OF32HTOF3
DNPFF-HPG-04-04-C-SAEFF-HPG-04-04-N-SAE
The dimensions may be different. Please review the drawings prior to ordering. Magister Hydraulics does not guarantee the identical product match.
