3.5" bore x 8" stroke CROSS rephasing tie rod hydraulic cylinder DR

Name: 3.5" bore x 8" stroke CROSS rephasing tie rod hydraulic cylinder DR
Brand: Magister Hydraulics
SKU: 3508DR
Price: 472.87 USD
Availability: InStock
Rating: 5 (10 reviews)

$472.87

SKU: 3508DR

Bore :	3.5 inch
OD :	4.25"
Stroke :	8” Stroke Hydraulic Cylinders
Rod :	1.25"
Port Size :	1/2" NPT
Pin :	1"
Extended :	28.25"
Retracted :	20.25"
Overall length :	30.25"
Pressure :	2500 PSI
Oil Volume (quarts) :	1.33
Brand :	CROSS MANUFACTURING
GTIN :	00015202733038

SKU: 3508DR Categories: Hydraulic Cylinders, Rephasing Hydraulic Cylinders

In stock

DESCRIPTION

3.5″ bore x 8″ stroke the CROSS series DR tie rod rephasing hydraulic cylinder 2500PSI made in the United States. Heavy-duty hydraulic equipment, 1-year warranty, free ground Continental US shipping. CROSS Manufacturing cylinders manufactured with high quality raw materials and american labor. These cylinder incorporate an internal mechanism for automatic raphasing in a series circuit, may be used as master or slave unit with DC cylinders. Precision finished ST52.3 steel cylinder barrels and polished induction hardened C1045 stell alloy rods, upgraded hevy-duty seals provide a long life for CROSS hydraulic cylinders. Ductile iron screw on clevis and double ported base for easy connection. High tensile strength tie rods with rolled threads for durability. Piston produced by high strength aluminum alloy with crown seal. Double lipped u-cup rod seals. 1/2″ NPT ports in line with pins. Hardened steel pins. Excellent replacement for farming equipment and others. Made in the USA.
FREE SHIPPING
